Description
Description
The New Kon 10-905 uses electric punching with an 8-character fixed-text line plus manually selected date/number line.
Features
- Electric punching creates permanent hole markings without marking ink.
- 8-character fixed-text line plus manually selected date/number line.
- Set dates or numbers manually using the pin mechanism.
- Use fewer sheets with thicker paper or denser die layouts.
Specifications
| Listed Die Configuration | 8-character fixed-text line plus manually selected date/number line |
|---|---|
| Die Selection Mechanism | Pin |
| Recommended Paper Capacity | Up to 14 sheets of 64 g/m² paper; use fewer sheets of 70–80 g/m² office paper |
| Capacity Conditions | Actual capacity depends on paper thickness, die layout, pin diameter and number of perforations |
See Additional Information for full specifications.
Die configuration and ordering
The upper line is fixed text; set the lower date or number line manually with the pin mechanism.
Marking options: DIBAYAR, PAID, JELAS, LHDN and LULUS; TELAH BAYAR or TELAH DIBAYAR require a suitable approved die layout.
Date layout: DD.MM.YY, e.g. 31.08.57, or an agreed eight-position layout.
When ordering, specify the wording, number of lines, spaces, date separators and whether the mark should read from the top or bottom of the document.
Electrical connection
Match the machine or adapter voltage and frequency to your power supply before connecting it.
Enquiries in Malaysia
Contact WOW Supplies in Puchong, Selangor, Malaysia for New Kon 10-905 enquiries, compatible supplies and product support.
Product images and videos
Frequently asked questions
Which marking does this New Kon 10-905 listing produce?
8-character fixed-text line plus manually selected date/number line.
How many sheets should I perforate at a time?
Up to 14 sheets of 64 g/m² paper; use fewer sheets of 70–80 g/m² office paper. Capacity also depends on the die layout, pin diameter and number of perforations. These are WOW Supplies working recommendations.
Does the date change automatically?
No. The upper line is fixed text; set the lower date or number line manually with the pin mechanism. Electric punching does not automatically update the date.
