Description
- Maximum tape width: up to 24 mm (print width up to 18.0 mm)
- Print speed: up to 30 mm/sec with USB-PD adapter; up to 20 mm/sec on battery
- Print resolution: 180 dpi / 128 dot
- Tape compatibility: TZe, TZe-SL, HGe, and HSe heat-shrink tubing
- Cutting mechanism: automatic full and half cutter
- Connectivity: Bluetooth 5.0 (SPP/iAP) and USB 2.0 Full Speed
- Memory: storage for up to 99 files and 1,800 characters
Print Speed and Tape Compatibility
The Brother PT-E560BTVP handles tape widths of 3.5 mm, 6 mm, 9 mm, 12 mm, 18 mm, and 24 mm across TZe, TZe-SL, HGe, and HSe tube types. It achieves print speeds up to 30 mm per second with the optional USB-PD adapter, or up to 20 mm per second on battery power. Output delivers 180 dpi resolution with support for up to seven printed lines on 24 mm tapes.
Cutting Functions and Dedicated Templates
An integrated automatic cutter executes both full and half cuts, keeping sequential labels organised on an easy-peel backing strip. One-touch keys provide immediate formatting for cable wrap, cable flag, faceplate, patch-panel, and punch-down block tasks. Built-in assets include 684 characters, 476 symbols, standard 1D barcodes, 2D barcodes, QR codes, and dual-increment advanced serialisation.
Connectivity and Standalone Controls
Bluetooth 5.0 links the device to mobile devices running the Pro Label Tool application, while USB 2.0 allows connection to computers running P-touch Editor. For standalone field operation, the unit incorporates a QWERTY keyboard, an 18-character by 3-line display, and onboard storage holding up to 99 files.
Supplied Kit Items
The package includes a protective hard carrying case, a rechargeable lithium-ion battery, a one-metre black USB Type-C cable, a 24 mm black-on-white Flexible ID laminated tape cassette, and documentation.
