Description
- Print speed: 25 sec/page on A1 (82 A1 prints per hour)
- Print resolution: Up to 2400 x 1200 optimized dpi
- Media handling: Sheet feed, roll feed, automatic sheet feeder, media bin, automatic horizontal cutter
- Supported media sizes: Auto sheet feeder: A4, A3; manual feed: A4, A3, A2, A1, A0; rolls: 279 to 914 mm
- Connectivity: Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi 802.11a/b/g/n, Wi-Fi Direct
- Memory: 1 GB
Media handling and multi-size printing
The HP DesignJet Studio Wood 36-in Printer incorporates an automatic sheet feeder alongside roll feed and manual sheet feed mechanisms. Users can output multi-size A3/B and A0/E projects automatically without manually switching the media source, supported by an integrated automatic horizontal cutter and media bin. Standard roll widths span 279 to 914 mm, with manual sheet feeding accommodating sizes from A4 to A0.
Print performance and ink system
Operating on HP Thermal Inkjet technology, this unit achieves print speeds of 25 sec/page on A1, equivalent to 82 A1 prints per hour, with line accuracy of ±0.1%. The four-colour ink system uses dye-based cyan, magenta, and yellow inks alongside pigment-based black ink, delivering print resolution up to 2400 x 1200 optimized dpi. The printer is equipped with 1 GB of memory and supports HP-GL/2, HP-RTL, CALS G4, JPEG, and URF print languages.
Connectivity and workflow integration
Standard network and device connections comprise Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi 802.11a/b/g/n, and Wi-Fi Direct. Remote print capability allows print jobs and large-format workflows to be managed via the HP Smart app. Files of multiple sizes can be submitted for printing in one click.
Physical configuration and box contents
The printer measures 1317 x 555 x 932 mm and weighs 41.7 kg. The package includes the HP DesignJet Studio 36-in Printer, a printer stand, automatic sheet feeder, roll cover, printhead, introductory ink cartridges, spindle, power cord, setup poster, and quick reference guide.
Power consumption and warranty support
Power usage is rated at <35 W during printing, <5.6 W in ready mode, <2.1 W in sleep mode, and <0.2 W when switched off. The unit comes with Standard 1 yr Next Business Day onsite support.
