Description
- Print speed: 116 A1/hr, 26 sec/A1
- Print resolution: Up to 2400 x 1200 optimized dpi
- Ink system: 6 inks (cyan, magenta, yellow, photo black, matte black, gray)
- Memory and storage: 128 GB virtual memory, 500 GB self-encrypting storage
- Media handling: Sheet feed, roll feed, automatic horizontal cutter
- Media sizes: A4, A3, A2, A1, A0 (metric rolls 279 to 1118-mm)
- Print languages: Adobe PostScript 3, Adobe PDF 1.7 ext 3, HP-GL/2, TIFF, JPEG, URF, CALS G4
Processing and File Handling
The printer uses an Adobe PDF driver and the Adobe PDF Print Engine to process complex layers of CAD and GIS data. It includes 128 GB of virtual memory and a 500 GB self-encrypting internal hard drive to support file processing without PC interruptions. Users can submit project sets and PDF documents using HP Click printing software.
Printhead and Ink System
The HP Thermal Inkjet system operates with three universal printheads covering two colours each, alongside six HP Bright Office Inks. The configuration employs dye-based cyan, magenta, yellow, photo black, and gray, alongside pigment-based matte black. It delivers up to 2400 x 1200 optimized dpi resolution with ±0.1% line accuracy and prints an A1 sheet in 26 seconds.
Media Handling and Formats
The 1118 mm printer accepts one roll and handles standard metric roll widths from 279 to 1118-mm, as well as sheet feed. Output handling incorporates an automatic horizontal cutter. Supported sheet and roll sizes include A4, A3, A2, A1, and A0 formats.
Device Security and Management
Integrated HP Wolf Pro Security features protect the hardware and stored data against unintended or external access. Fleet, device, and security management tools help administrators oversee the printer, while accounting solutions assist with expense tracking. Network integration is supported via Gigabit Ethernet (10/100/1000Base-T) alongside a USB Type-A host port.
Supplied Items and Warranty
The package includes the HP DesignJet T1700 Printer, printheads, ink cartridges, printer stand, spindle, setup poster, introductory documentation, power cords, and label kits. Warranty coverage provides Standard 2 yrs Next Business Day onsite support.
