Description
- Print speed: 116 A1/hr, 26 sec/A1
- Print quality: Up to 2400 x 1200 optimized dpi
- Finished output handling: Sheet feed, two automatic roll feeds, automatic roll-switching, media bin, automatic horizontal cutter
- Ink types: Dye-based (C, M, Y, PK, G); pigment-based (MK)
- Storage and memory: 500 GB self-encrypting internal storage, 128 GB virtual memory
- Connectivity: Gigabit Ethernet, 10/100/1000Base-T Ethernet, USB Type-A host port
Dual-Roll Media Handling
This 1118 mm model provides two automatic roll feeds and automatic roll-switching to maintain continuous workflow. Finished output handling incorporates a sheet feed, an automatic horizontal cutter, and an integrated media bin. Supported metric roll widths range from 279 to 1118 mm, handling paper sizes from A4 to A0.
Six-Ink Printing System
The printer operates with six ink cartridges combining dye-based cyan, magenta, yellow, photo black, and gray with pigment-based matte black. This arrangement provides soft colours and dark tones with print resolution up to 2400 x 1200 optimized dpi. Cartridges are available in 130 ml and 300 ml capacities, delivering line accuracy of ±0.1%.
File Processing and Software
Equipped with 128 GB of virtual memory and a 500 GB self-encrypting hard drive, the unit processes complex CAD and GIS files without overburdening host computers. Supported print languages include Adobe PostScript 3, Adobe PDF 1.7 ext 3, HP-GL/2, TIFF, JPEG, URF, and CALS G4. The Adobe PDF Print Engine renders layered data, while HP Click printing software assists with printing project sets and PDF documents.
Security and Network Connectivity
Network integration is provided via Gigabit Ethernet alongside a USB Type-A host port. Built-in security features include HP Wolf Pro Security, HP Secure Boot, allowlisting, Role Based Access Control, HTTPS, IPsec/Firewall, 802.1X, self-encrypting HDD, Secure Disk erase (DoD 5220.22-M), and PIN printing. The unit is compatible with HP Web Jetadmin and HP JetAdvantage Security Manager.
Physical Dimensions and Warranty
The printer measures 1802 x 695 x 998 mm and has a weight of 89.4 kg. Coverage includes standard 2 yrs Next Business Day onsite support.
