Description
- Print resolution: Up to 2400 x 1200 optimized dpi
- Media handling: Sheet feed, roll feed, automatic sheet feeder, media bin, automatic horizontal cutter
- Supported media sizes: Auto sheet feeder: A4, A3; manual feed: A4, A3, A2, A1
- Network and wireless: Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi 802.11a/b/g/n, Wi-Fi Direct
- Ink configuration: 4 (C, M, Y, K) with dye-based colour and pigment-based black
- Installed memory: 1 GB
Media handling and automated feeding
The HP DesignJet T650 24-in Printer handles roll feed and cut sheets using an automatic sheet feeder, sheet feed, media bin, and an automatic horizontal cutter. Media sizes supported include A4 and A3 through the auto sheet feeder, alongside A4, A3, A2, and A1 through manual feed. Custom media sizes range from 210 x 279 to 330 x 482 mm on the auto sheet feeder and 210 x 279 to 610 x 1897 mm on manual feed. Recommended media weights are 60 to 280 g/m² for roll or manual feed, and 60 to 220 g/m² for the auto sheet feeder. The system prints large- and small-format sheets automatically in a multi-size print basket.
Thermal inkjet imaging and ink supply
Printing via HP Thermal Inkjet technology, the device achieves up to 2400 x 1200 optimized dpi resolution. The imaging hardware uses 1 printhead containing 1376 print head nozzles linked to 4 print cartridges. The ink system employs dye-based cyan, magenta, and yellow inks alongside pigment-based black ink. Compatible media types include bond and coated paper (bond, coated, heavyweight coated, plain, bright white, blueprint), technical paper (natural tracing), film (clear, matte), photographic paper (satin, gloss, semigloss, polypropylene), and self-adhesive media (adhesive, polypropylene).
Connectivity, software, and power specifications
Standard connectivity comprises Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi 802.11a/b/g/n, and Wi-Fi Direct, backed by 1 GB of memory. Included software tools are HP Click App, HP Click Driver for Windows 11, HP Smart app, HP Print Preview for Windows, HP Easy Start, HP DesignJet Utility for Windows, and HP Support Assistant. One-click printing operates through HP Click software for PDF, JPEG, TIFF, DWF, and HP-GL/2 files. Operational power consumption description states <35 W while printing, <5.6 W ready, <2.1 W sleep, and <0.2 W standby. Warranty coverage is Standard 1 yr Next Business Day onsite support.
