Description
- Print resolution: Up to 2400 x 1200 optimized dpi
- Print speed: Fast-Economode: 71.4 m²/hr on plain media; Normal: 22.4 m²/hr on coated media; Best: 4.5 m²/hr on glossy media
- Ink system: 9 pigment-based print cartridges with 5 universal printheads
- Media handling: Roll feed, rear sheet feed, media output bin, automatic horizontal cutter
- Media roll widths: 279 to 1118 mm
- Memory and storage: 128 GB (virtual) memory and 500 GB self-encrypting internal storage
Print Quality and Ink Technology
This model utilises HP Thermal Inkjet technology with 9 pigment-based ink cartridges, including chromatic red, chromatic green, chromatic blue, and gray, alongside an optional gloss enhancer. Dual-drop weights of 7/3 pl and single-drop weights of 6 pl operate across 5 universal printheads to deliver up to 2400 x 1200 optimized dpi. Built-in spectrophotometer hardware and HP Pixel Control manage colour consistency and gradient transitions across print jobs.
Media Handling and Output Operations
The printer supports standard metric rolls from 279 to 1118 mm with recommended media weights between 80 to 500 g/m² and media thickness up to 0.8 mm. Media feeding options include roll feed and rear sheet feed, accompanied by an automatic horizontal cutter and a media output bin. Print speeds reach 71.4 m²/hr on plain media in Fast-Economode, 22.4 m²/hr on coated media in Normal mode, and 4.5 m²/hr on glossy media in Best mode.
Processing, Connectivity, and Security
System processing is supported by 128 GB (virtual) memory, a 500 GB self-encrypting hard drive, and native Adobe PostScript 3 and Adobe PDF 1.7 print languages. Network integration is provided via Gigabit Ethernet (1000Base-T), complemented by a Hi-Speed USB 2.0 certified interface for direct printing from a USB flash drive. Device operations and print files are protected by HP Wolf Pro Security features alongside HP Click job submission software.
Included Equipment and Support
Supplied hardware includes the HP DesignJet Z9+ PostScript Printer, printheads, introductory ink cartridges, a printer stand and media bin, a spindle, a 3-in core adapter, a setup poster, a quick reference guide, and a power cord. Hardware support includes Standard 2 yrs Next Business Day onsite support.
