Description
- 3,300 lm light output.
- XGA (1024 x 768 pixels) resolution.
- 15,000:1 contrast ratio (Iris: On).
- 0.76–7.6 m (30–299 in) screen size at 4:3 aspect ratio.
- 10,000 hours lamp replacement cycle in NORMAL mode, the maximum value at which brightness has fallen to 50%.
- 20,000 hours lamp replacement cycle in ECO mode, the maximum value at which brightness has fallen to 50%.
- Manual vertical and horizontal keystone correction of ±30 °.
Projection specification
The PT-LAX35 uses a Transparent LCD panel (x 3, R/G/B). Its stated light output is 3,300 lm, with XGA (1024 x 768 pixels) resolution and a 15,000:1 contrast ratio (Iris: On). The stated screen-size range is 0.76–7.6 m (30–299 in) with a 4:3 aspect ratio. Manual vertical and horizontal keystone correction are each stated as ±30 °.
Connections and control
The specifications list HDMI 19P x 1, with HDCP and Deep Color compatibility, plus D-sub HD 15-pin (female) x 1 [RGB]. The RJ-45 x 1 LAN connection supports 10Base-T/100Base-TX and PJLink™ (Class 1). A D-sub 9P (male) x 1 serial input is RS-232C compatible for external control. USB Type-A supports Memory Viewer and an optional wireless module.
Operating details
The listed built-in speaker is 5 W monaural. Operation noise is stated as 38 dB [NORMAL] and 35 dB [ECO]. Dimensions are 345 x 99* x 261 mm, with legs at the shortest position, and the stated weight is Approx. 3.1 kg.
Listed supplied accessories
The supplied list includes HDMI cable x 1, wireless remote control unit x 1, quick start guide and batteries for remote control (R03/LR03/AAA type x 2). It also lists power cord x 1; the number and size of cords depends on region.
Warranty
2 years set warranty against manufacturing defects & 1,000 hrs or 1 year lamp warranty whichever comes first for LAX Series.
