Description
- Resolution: 4K (3840 x 2400) with Quad Pixel Drive, based on a native 1920 x 1200 panel.
- Light output: 15,000 lm, with listed ANSI output of 15,000 lm and Centre output of 15,500 lm.
- Projection technology: 1-Chip DLP™ projector with a Laser diode light source.
- Contrast ratio: 25,000:1 (Full On/Full Off, Dynamic Contrast).
- Screen size: 70–1000 inches with ET-C1S600.
- Connections: HDMI™ x 2, DisplayPort™ x 1, and an Intel® SDM standard-compatible function-board slot.
- Installation: Ceiling or floor placement, front or rear projection, and free 360-degree installation.
Projection specification
The PT-REQ15 is specified with 4K (3840 x 2400) resolution with Quad Pixel Drive. Its native panel is 1920 x 1200. Its listed light output is 15,000 lm. The Panasonic specifications also state 15,000 lm (ANSI) and 15,500 lm (Center). The projector uses a Laser diode light source and has a stated contrast ratio of 25,000:1 (Full On/Full Off, Dynamic Contrast).
Installation and connections
The stated screen-size range is 70–1000 inches with ET-C1S600. Installation options are ceiling or floor placement, front or rear projection, and free 360-degree installation. HDMI™ x 2 and DisplayPort™ x 1 are listed with Deep Color, HDCP 2.3 compatibility, and 4K/60p signal input. The projector also has an open slot for function boards compatible with the Intel® SDM standard. NFC is supported, and LAN control supports Crestron Connected™ V2, Crestron XiO Cloud™, Art-Net DMX, AMX® DD, and PJLink™ (Class 2).
Product details
Time until light output declines to 50 % is listed as 20,000 hours [NORMAL], 24,000 hours [ECO], and 20,000 hours [QUIET]. Weight is Approx. 28.7 kg with supplied lens, and body colour is Black. A supplied lens is listed. The stated warranty is 3 years set warranty against manufacturing defects & 10,000 hrs whichever comes first for LASER projectors.
