Description
- 4K (3840 × 2400 pixels) displayed resolution with Quad Pixel Drive [ON]
- 7,300 lm light output
- Laser diodes in an LCD projector
- 0.76–7.62 m (30–300 in) screen size, 16:10 aspect ratio
- 1.6x manual zoom lens with 1.09–1.77:1 throw ratio
- Vertical lens shift +44 % and horizontal lens shift ±20 % from center of screen
- HDMI input: 19-pin x 2, with HDCP, Deep Color and 4K/60p signal input compatibility
Projection and adjustment
The Panasonic PT-VMQ75 is an LCD projector. Its display device has 2,304,000 (1920 x 1200) pixels. The Digital Zoom Extender has a 1.09–2.21:1 throw ratio when used together with optical zoom. Panasonic lists these specifications as preliminary.
Connections
HDMI output x 1 is provided. DIGITAL LINK IN / LAN uses RJ-45 x 1 for video, network and serial control, and is HDBaseT compliant. A separate LAN terminal uses RJ-45 x 1 for network control and is compatible with PJLink [Class 2].
Control ports
USB Type A x 1 supports Memory Viewer, an optional AJ-WM50 Series Wireless Module and power supply at DC 5 V, maximum 2 A. SERIAL IN uses D-sub 9-pin (female) x 1 for RS-232C computer control. Audio input and audio output each use M3 stereo mini-jack x 1.
Included item and warranty
Supplied items listed by Panasonic include a filter. The set warranty is 3 years against manufacturing defects & 10,000 hrs whichever comes first for LASER projectors.
