Description
- Maximum tape width: 18 mm (supports 3.5 mm, 6 mm, 9 mm, 12 mm, and 18 mm TZe tapes)
- Print speed: up to 30 mm/sec at 180 dpi resolution
- Connectivity: Bluetooth Classic (SPP) and USB 2.0 Micro-B
- Display and input: 20-character by 2-line graphic LCD with QWERTY keyboard
- Line capacity: up to 5 lines of text on 18 mm tape
- Memory: stores up to 70 label files with a 280-character buffer
- Power: AD-E001A AC adapter or 6 AA batteries (alkaline or Ni-MH)
Standalone and Connected Label Creation
The PT-D460BT operates as an independent desktop unit using its integrated QWERTY keyboard and two-line graphic screen. For label design on computers or smartphones, the unit connects via USB 2.0 Micro-B or Bluetooth Classic using the SPP profile. Print preview allows text verification on the display before outputting labels.
Tape Compatibility and Print Specifications
The thermal printer accepts Brother TZe tape cassettes in widths ranging from 3.5 mm to 18 mm. Output reaches speeds up to 30 mm per second at a resolution of 180 dpi. Text layout accommodates a single line on 3.5 mm tape, up to two lines on 6 mm and 9 mm widths, three lines on 12 mm tape, and up to five lines on 18 mm media.
Barcode Support and Onboard Memory
Built-in formatting tools include nine barcode protocols, covering CODE39, CODE128, EAN-8, EAN-13, ITF 2/5, UPC-A, UPC-E, CODABAR, and GS1-128. The internal storage holds up to 70 label templates for frequent retrieval, supported by a 280-character memory buffer. Additional print functions include copy printing and mirror printing.
Power Options and Physical Dimensions
Operational power is supplied by the AD-E001A AC adapter or six AA alkaline (LR6) or Ni-MH (HR6) batteries. An automatic power-off feature manages battery consumption during idle periods. The desktop casing measures 187 mm in width, 72 mm in depth, and 178 mm in height, with a machine weight of 0.77 kg.
