Description
- WUXGA resolution: 1920 x 1200 pixels
- 5,200 lm light output
- Laser diode light source
- Transparent LCD panel display method with x 3 R/G/B panels
- 0.76–7.62 m (30–300 in) screen size at 16:10 aspect ratio
- Vertical lens shift of +44 % and horizontal lens shift of ±20 % from center of screen
Projection adjustment
Keystone correction is Vertical: ±25 ° and Horizontal: ±35 °. It supports ceiling or floor positioning, front or rear projection, and free 360-degree installation.
Signal and control connections
Its HDMI input supports 4K/30p signal input and CEC commands. 4K signals are converted to the projector resolution upon projection. The DIGITAL LINK connection carries video, network and serial control through an HDBaseT-compliant RJ-45 terminal.
Control and USB functions
Network control supports PJLink [Class 2], while computer control supports RS-232C. The USB Type A connection supports Memory Viewer and the optional AJ-WM50 Series Wireless Module.
Light source and operating details
Light output declines to 50 % after 20,000 hours [NORMAL], 24,000 hours [ECO], or 20,000 hours [QUIET]. Operation noise is 36 dB [NORMAL] and 26 dB [QUIET]. The built-in speaker is 10 W monaural.
Warranty
The warranty is 3 years set warranty against manufacturing defects & 10,000 hrs whichever comes first for LASER projectors.
Included item
Supplied items listed by Panasonic include a filter.
